203 Integrated Double-swing Door

The Centor 203 Integrated Double-swing Door features a clean look, with equal-sized panels and simple lines. With a solid wood interior and thermally-improved aluminum construction, our 203 Double-swing Door will perfectly frame any view.

For inside-outside living without the compromises, Centor’s 203 Integrated Double-swing Door incorporates built-in screens and shades to control insects, sunlight and privacy. Our shades also enhance the thermal properties of the door, with independent tests showing that the blackout shade improves the U-factor by 17% when drawn across the opening.

  • Wood interior in five unfinished options or primed for painting.
  • Aluminum exterior in a range of standard or custom colors.
  • Engineered to last a lifetime – extrusions are painted after cutting and machining so all surfaces are coated, reducing the probability of filiform corrosion.
  • Hidden hardware including Access AutoLatch™ and AutoLatch™.
  • Integrated insect screens and shades are accessible for service or replacement.
  • Screen box facings are available to enable simple installation into an existing opening.
  • Double or triple glazing available.
Overall frame width
4' 8 ⅞" - 7' 7 ⅞" (1444 - 2334mm)
Visible frame width
4' ¼" - 6' 11 ¼" (1224 - 2114mm)
Frame height
6'-6 3/16" -10'-6 13/16" (1987 - 3222mm)
Panel width
1' 10 ⅝" - 3' 3 ⅜" (575 - 1000mm)
Panel height
6'-5/8" -10'-1 1/4" (1846 - 3081mm)
Loading
top
Opening
outward

Integrated French Door Diagram

Features
Access AutoLatch™

Centor’s latest locking innovation, the Access AutoLatch™ is available on doors that are Florida hurricane rated. It replaces the traditional entrance handle with a concealed version that’s hidden from view in the door stile.

Centor Access AutoLatch
Interior
The lever is simply lifted to open the doors from the inside. A ‘signifier’ on the face of the panel hints at the lever’s location.
access autolatch exterior handle
Exterior
On the exterior, a slimline vertical pull-handle allows panels to be opened with ease.
Traditional handle

As an alternative to the Access AutoLatch, Centor is pleased to offer a stylish modern traditional style handle.

Internal Handle with Snib
Internal Handle with Snib
External Handle with Cylinder
External Handle with Cylinder
AutoLatch™

The Centor AutoLatch™ is used to close and secure intermediate panels in one movement, with one hand. It is available keyed or non-keyed.

Centor AutoLatch for easily opening intermediate panels on folding doors
Centor AutoLatch™
0:26
Integrated screens and shades

Built into the door frame, our innovative integrated insect screens and shades are a world-first offering. They allow homeowners to enjoy inside-outside living without the compromises traditionally associated with large openings – insects, glare and loss of privacy.

Screens for Centor Integrated Doors are available in two mesh types to keep insects out while enjoying fresh air
Screens
Choose between two mesh types to keep insects out while enjoying fresh air – like Heather: “The insect screen is particularly great. Some mornings, I’ll just open two panels of the door, slide the screen across and the whole house benefits from a free flow of fresh air. It’s not intrusive at all.”
Shades for Integrated Doors are available in two patterns and a range of colours
Shades
Available in three patterns and a range of colors, our light-filtering and block-out shades retract from sight when not is use – which really appealed to Paul: “They’re neatly concealed in the end reveals... and when they’re not being used you don’t know they are there. It’s very clever design.”
Performance
Weather tests

200 Series Folding Doors have achieved the following performance levels when tested in accordance with the standards set by NFRC/AAMA/WDMA/CSA.

Primary Product Designator
Class – LC-PG55
USA Air Infiltration
0.13 cfm/ft² (0.65L/sm²) ASTM E283-04
Canadian Air Exfiltration
Level A3 0.13 cfm/ft² (0.68L/sm²)
Water Infiltration
8.35 psf (400 Pa)
Design Pressure
+/– 55 psf (+/- 2633 Pa)
Florida hurricane approved

200 Series door and windows are approved by the Florida DBPR for use in coastal zones. It is built to withstand coastal conditions such as fluctuating temperatures, burning sunshine, salt and wind.

Hurricane rating
Wind Zone 4 and HVHZ, Large and Small Missile impact
Thermal

The National Fenestration Rating Council is a non-profit organization that establishes objective window, door, and skylight energy performance ratings to help you compare products and make informed decisions. Centor Doors have been tested in accordance with NFRC 102-2010.

Double glazed: U-factor as low as 0.29 Btu/h ft²-°F
Triple glazed: U-factor as low as 0.23 Btu/h ft²-°F

Additionally, where blackout shades are used these values are improved by a further 17%.
