250 Integrated Fixed-lite

Connect to the beautiful world with the Centor 250 Fixed-lite window. The frameless design offers large expanses of fixed glass, with built-in shades to control glare and provide privacy. Like the fixed panel on the Centor 211 Integrated Sliding Door, the sill meets flush with the glazing for an unobstructed view to the outside.

Pair the 250 Integrated Fixed-lite alongside Centor Integrated Doors for a seamless aesthetic.

For inside-outside living without the compromises, the Centor 205 Integrated Fixed-lite incorporates built-in shades to control sunlight and provide privacy. Our shades also enhance the thermal properties of the window, with independent tests showing that the blackout shade improves the U-factor by 17% when drawn across the opening.

  • Wood interior in five unfinished options or primed for painting.
  • Aluminum exterior in a range of standard or custom colors.
  • Engineered to last a lifetime – extrusions are painted after cutting and machining to ensure all surfaces are coated.
  • Integrated shades are accessible for service or replacement.
  • Double or triple glazing available.
Overall frame width
3’ 4 ½” – 19' 10 ⅝" (1030 – 6060mm)
Visible frame width
2’ 7 ⅞” – 19' 1 ⅞" (810 – 5840mm)
Frame height
5’ – 9' 5 ½" (1524 – 2884mm)

*Fixed-lite with visible frame width over 15' 3 ⅜" (4657mm) available with a double shade
 Fixed-lite single pane visible frame width maximum 78 ¾”

Image removed.

Features
Panel configurations

The Centor 250 Integrated Fixed-lite is available with a single pane or multiple panes. Regardless of the number you specify, each pane must be of equal width.

Your Centor Integrated Dealer can help you decide on maximum pane widths.

Single pane 250 fixed lite window
Multiple pane 250 fixed lite window
Integrated shades

Built into the window frame, our innovative, fully retractable shades are a world-first offering. They allow homeowners to enjoy inside-outside living without the compromises traditionally associated with large openings, including glare and loss of privacy.

Available in three patterns and a range of colours, our light-filtering and block-out shades retract from sight when not is use – which really appealed to Gillian in County Durham: “I didn’t want any curtains in my house, but I wanted the capability to occasionally block the light out and to close the windows off at night.”

Shades for Centor doors are fully retractable into the door frame
Shades for Centor Doors are available in two patterns and a range of colours
Performance
Air, water and structural

Based on 211 Integrated Sliding Door testing, the following performance levels were achieved in accordance with the standards set by NFRC/AAMA/WDMA/CSA.

Hurricane rating
Impact (Large Missile) for Wind Zone 4
USA Air Infiltration
0.11 cfm/ft²
Canadian Air Exfiltration
A2 (0.11 cfm/ft²)
Water Infiltration
6.89 psf (330 Pa)
Design Pressure
+/– 75 psf
Thermal

Double glazed: U-factor as low as 0.28 Btu/h ft²-°F
Triple glazed: U-factor as low as 0.21 Btu/h ft²-°F

Additionally, where blackout shades are used these values are improved by a further 17%.

Test results have not yet been third party verified. Final results may vary.
