205 Integrated Folding Door

German Design Award Gold 2017
reddot design award winner 2015

The 205 is Centor’s flagship Integrated Folding Door, featuring a solid wood interior and thermally-improved aluminum construction. Perfectly framing any view, the clean design on our 205 Integrated Folding Door sees all visible hardware removed from the interior, with equal stiles and rails on each panel frame.

Many configurations are possible with this option – including doors with 2 panels or 4 panels in one direction now having full key access from the outside.

For inside-outside living without the compromises, the Centor 205 Integrated Folding Door incorporates built-in screens and shades to control insects, sunlight and privacy. Our shades also enhance the thermal properties of the door, with independent tests showing that the blackout shade improves the U-factor by 17% when drawn across the opening.

  • Large doors up to 30’ 2 ¾” (9214mm) wide.
  • Wood interior in five unfinished options or primed for painting.
  • Aluminum exterior in a range of standard or custom colors.
  • Engineered to last a lifetime – extrusions are painted after cutting and machining so all surfaces are coated, reducing the probability of filiform corrosion.
  • Hidden hardware, including Access AutoLatch™, AutoLatch™ and concealed hinge.
  • Integrated insect screens and shades are accessible for service or replacement.
  • Screen box facings are available to enable simple installation into an existing opening.
  • Double or triple glazing available.
Overall frame width
4' 8 ½" – 30' 11 ⅜" (1434 – 9434mm)
Visible frame width
3' 11 ¾" – 30’ 2 ¾” (1214 – 9214mm)
Frame height
6'-6 3/16" -10'-6 13/16" (1987 - 3222mm)
Panel width
1' 9 ⅞" – 3' 8 ½" (555 – 1130mm)
Panel height
6'-5/8" -10'-1 1/4" (1846 - 3081mm)
Loading
top
Opening
outward

* 205 Folding Doors over 15’ 3 ⅜” (4657mm) available with the choice of either a screen or shade.

Integrated Folding Door Diagram

Features
Access AutoLatch™

Centor’s latest locking innovation, the Access AutoLatch™ is available on doors that are Florida hurricane rated. It replaces the traditional entrance handle with a concealed version that’s hidden from view in the door stile.

Centor Access AutoLatch
Interior
The lever is simply lifted to open the doors from the inside. A ‘signifier’ on the face of the panel hints at the lever’s location.
access autolatch exterior handle
Exterior
On the exterior, a slimline vertical pull-handle allows panels to be opened with ease.
Performance
Weather tests

200 Series Folding Doors have achieved the following performance levels when tested in accordance with the standards set by NFRC/AAMA/WDMA/CSA.

Primary Product Designator
Class – LC-PG55
USA Air Infiltration
0.13 cfm/ft² (0.65L/sm²) ASTM E283-04
Canadian Air Exfiltration
Level A3 0.13 cfm/ft² (0.68L/sm²)
Water Infiltration
8.35 psf (400 Pa)
Design Pressure
+/– 55 psf (+/- 2633 Pa)
Downloads
205 Folding Outward Opening, 7 ⅞” (200mm) sill
205 Folding Outward Opening, 8 ⅞” (230mm) sill with exterior jamb facing
Folding handle heights
pdf
205 Impact Folding Glass Door – Large & small missile impact
pdf
205 Impact Folding Glass Door – Engineering evaluation report
pdf
2x6 Wall with Siding Facade, Wood Framed Floor
2x6 Wall with Siding Facade, Concrete Slab
2x6 Wall with Brick Facade
CMU Wall with Brick Facade
